15-5 Stainless Steel - Sheet, Plate, Bar, Forged Bar

 UNS S15500, AMS 5659, AMS 5862, ASTM A564

* All Trademarks and/or Trade names are the properties of their respective owners.


15-5 Stainless Steel Specifications:
AMS 5659, AMS 5862, ASTM A564

Alloy 15-5, Alloy 15-5 PH, 15-5 PH Stainless Steel, 15-5 PH sheet, 15-5 precipitation hardened (PH) stainless steel sheet, UNS S15500

15-5 Stainless Steel Available Forms:
15-5 Alloy Sheet, 15-5 Alloy Plate, 15-5 Alloy Bar, 15-5 Alloy Forged Bar


15-5 Stainless Steel Applications: Stainless Steel Alloy 15-5 is used in industrial applications, especially for the aerospace, food service, metalworking, chemical and petrochemical industries.


15-5 PH stainless steel offers high strength and hardness with excellent corrosion resistance. SS 15-5 can be age-hardened by a low temperature treatment. 15-5 PH stainless steel offers good corrosion resistance, and high strength therefore has been used for aerospace applications.


15-5 PH stainless steel includes high levels of chromium, nickel and copper. Carbon, manganese, phosphorus, sulfur, silicon and columbium plus tantalum may also be present in trace amounts, with each not exceeding 1 percent of the compositional total.

Physical Properties

Melting Point: 2560 - 2625°F (1404 – 1440°C)
Density: 0.282 lbs/in3 / 7.78 g/cm3
Modulus of Elasticity in Tension: 28.5 X 106 psi / 196 GPa

Mechanical Properties

Condition: Solution Treated (A) Tensile Strength Minimum (psi): 160,000
Yield Strength Minimum 0.2% offset (psi): 140,000
% Elongation in 2” Typical: 8%
Hardness: Rockwell C35

Condition: Aged (H1075) Tensile Strength Typical (psi): 162,000
Yield Strength Typical 2% offset (psi): 160,000
% Elongation in 2": 12%
Hardness: Rockwell C38

Condition: Aged (H900) Tensile Strength Typical (psi): 210,000
Yield Strength Typical 2% offset (psi): 200,000
% Elongation in 2": 9%
Hardness: Rockwell C46

Heat Treatment
15-5 is typically supplied in Condition A, and can be heat treated at a variety of temperatures and times to achieve a wide range of properties.

Corrosion Resistance

The general level of corrosion resistance exceeds that of Types 410 and 431, and is approximately equal to that of Type 17-4 PH stainless steel as indicated by laboratory tests in both strongly oxidizing and reducing media, as well as by atmospheric exposures. The general level of corrosion resistance is best in the fully hardened condition, and decreases slightly as the aging temperature is increased.

California Metal & Supply is a leading supplier of quality 15-5 Stainless Steel Sheet, 15-5 Stainless Steel Plate, 15-5 Stainless Steel Bar, 15-5 Stainless Steel Forged Bar.

All of our 15-5 PH stainless steel is ordered to specific thickness. We supply 15-5 PH stainless steel and are capable of fulfilling your required lengths and widths. California Metal & Supply Inc. also has a stocking program to support long term contract for your 15-5 PH stainless steel needs.
